Carbide V Groove Chamfer Drill Bits For Aluminum & Steel

Short Description:

Solid Carbide chamfering tools are an excellent choice for cutting chamfers and deburring machined edges in manual and CNC applications. 3 Flute design and also be used to spot drill holes in soft materials.


Product Detail

FAQ

Product Tags

Product Presentation

Solid Carbide chamfering tools are an excellent choice for cutting chamfers and deburring machined edges in manual and CNC applications. 3 Flute design and also be used to spot drill holes in soft materials.
The Router Bits Are Super for Carving V Groove, CNC Lettering And Signs, And Chamfering End.
3 Flutes Designed Chamfer Bits to make Cutting More Efficiently And Clean Surface.
V Groove Router Bits Can Be Used in CNC, X carve, 3D carving, Router Hand And Table Mount, And Most Brand Handheld Routers with 1/4 Inch Collets.

Product Parameter

Type Flat surface
Flutes 3
Workpiece Material Cast iron, carbon steel, copper, stainless steel, alloy steel, modulation steel, spring steel (steel), aluminum, aluminum alloy, magnesium alloy, zinc alloy (aluminum), etc
Processing way Plane/side/groove/cut-in (Z-direction feed)
Brand Xinfa
Coating No
Flute Diameter D Flute Length L1 Shank Diameter d Length L
1 3 5 50
1.5 4 4 50
2 6 4 50
2.5 7 4 50
3 9 6 50
4 12  6 50
5 15 6 50
6 18 6 60
8 20 8 60
10 30 10 75
12 32 12 75
16 45 16 100
20 45 20 100

  • Previous:
  • Next:

  • Q1:Can I have a sample for testing?
    A: Yes, we can support sample. The sample will be charged reasonably according to the negotiation between us.

    Q2:Can I add my logo on the boxes/cartons?
    A:Yes,OEM and ODM are available from us.

    Q3: What are the benefits of being a distributor ?
    A: Special discount Marketing protection.

    Q4:How can you control the quality of products?
    A: Yes, we have engineers ready to assist customers with technical support problems, any issues that may arise during the quoting or installation process, as well as aftermarket support. 100% self-inspection before packing.

    Q5:Can I have a visit to your factory before the order?
    A: Sure,welcome your visit of factory.
